PRO-REVERB AMP
CABINET ASSEMBLY (cont)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0027846000 HANDLE 9.25" NO LOGO
1 0032524000 INSERT HANDLE
2 0019279000 HANDLE CAP 2 HOLE NICKEL
16 0027199000 SCRW SMAB 10 X 3/4 PHP NI
4 0026571000 SCRW SMAB 8x5/8 THP NI
8 0021972000 NUT T 10-32x3/4 STR 3 PRNG BLX
4 0022244000 SCRW M10-32 x 1 1/8 OHP NI
4 0026625000 SCRW WOOD 8x1 FH
REF 0029086000 VELCRO STRIP HOOK 1.5" wd BLK
REF 0029085000 VELCRO STRIP LOOP 1.5" wd BLK
REF 0026570000 TOLEX "BRAVURA BLACK"
REF 0037788000 CLOTH GRILLE BLACK/SILVER
REF 0037350000 TAPE ALUM 8"X60YDS
END ITEM ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0056523000 CABINET ASSY PRO REVERB
1 0057056000 CHASSIS ASSY. PRO REVERB 120V DOM
REF 0057223000 CHASSIS ASSY. PRO REVERB 230V UK
REF 0057058000 CHASSIS ASSY. PRO REVERB 240V AUS
REF 0057059000 CHASSIS ASSY. PRO REVERB 100V JPN
1 0047248000 CORD PWR W/IEC CONN DOM
REF 0047251000 CORD PWR W/IEC CONN 230V EUR
REF 0047249000 CORD PWR W/IEC CONN 230V UK
REF 0047250000 CORD PWR W/IEC CONN 240V AUS
REF 0053997000 CORD PWR W/IEC CONN 100V JPN
2 0051478000 LEG AMP TILTBACK 14" @ CAB SIDES
2 0021998000 NUT FLEX LOCK 10-32 W/NYLON IN @ TILTBACK LEGS
2 0022277000 SCRW M 10-32x1-1/2 OHP NI @ TILTBACK LEGS
2 0022285000 WSHR SP LOCK 1/4x.493 ZI @ TILTBACK LEGS
6 0022319000 WSHR FLAT 1/4x9/16 NI @ TILTBACK LEGS
2 0031344000 SCRW SMA 10x3/4 OHP NI @ TILTBACK LEG STOPS
2 0024646000 WASHER LEG STOP TN @ CAB SIDES
1 0057025000 FOOTSWITCH ASSY 4 BUTTON
1 0064063000 REVERB UNIT 4 SPRING 4AB3C1B INSIDE REV. BAG
1 0031849000 REVERB BAG @ CAB BOTTOM
1 0028453000 PAD CARDBOARD REVERB INSIDE REV. BAG
1 0057065000 SPEAKER 12" 8OHM JENSEN C12N @ BAFFLE
4 0029828000 SCRW PB 8x3/4 PHP ZI @ REV. BAG & CABLE CLAMPS
2 0022327000 WSHR FLAT 8x7/16 NI @ REV. BAG SCREWS
1 9906900590 CLAMP CABLE NYL ADHESIVE @ REV. UNIT
1 0012582000 CLAMP CABLE NYL SCRW MNT 1/4 @ REV. CABLE
1 0025722000 CABLE REVERB 1100mm CHASSIS TO REV. UNIT
1 0028044000 CABLE ASSY SPKR RT ANG 33" @ SPKR TO MAIN SPKR JCK
1 0022491000 CLAMP CABLE NYL SCRW MNT 5/16 @ SPKR CABLE
4 0026577000 SCRW M 10-32x1 PHP BLX @ SPEAKER
2 0024752000 STRAP CHASSIS 4-1/2" NICKEL CHASSIS TO CAB
To Next Page
