PRO-REVERB AMP
CHASSIS ASSEMBLY (cont)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
2 0014172000 SCREW M 4-40 x 1/4 PHP BLX @ IEC PWR JACK
1 0036702000 FUSE HOLDER 3AG FINGER GRIP @ LINE FUSE F1 (120V/100V UNITS)
1 0077982000 FUSE QA 1-1/4x1/4" 250V 3A LINE FUSE F1 (120V/100V UNITS)
REF 0036703000 FUSE HOLDER 5MM FINGER GRIP @ LINE FUSE F1 (230V/240V UNITS)
REF 0013115000 FUSE TD 20mmx5mm 250v T2A LINE FUSE F1 (230V/240V UNITS)
REF 0057185000 20mm x 5mm INLINE FUSEHOLDER ASSY 230V & 240V UNITS
1 0021550000 JACK PHONE TIP SHUNT 12A MAIN SPKR JACK J11
1 0041701000 JACK PHONE TRANSFER 13A EXT. SPKR JACK J12
15 0024604000 KNOB BLACK W/WHITE STAMP 1-10 @ ALL CONTROLS
1 0057045000 CHASSIS PRO/CONCERT REVERB
1 0057032000 COVER BOX BIAS CONTROLS PRO-TUBE AMPS
1 0057046000 PANEL, FRONT PRO REVERB
1 0057047000 PANEL, REAR PRO/CONCERT REVERB
2 0023572000 TUBE 7025/12AX7A CHINESE V1-2
5 0013341000 TUBE 7025/12AX7WA RUSSIAN MADE V3-6 V8
1 0023531000 TUBE 12AT7 HIGH MU TWIN TRIODE V7
8 0053893000 TUBE SHIELD SUNN MODEL T V1-8
2 0053980000 TUBE VACUUM 6L6GC/5881 SVTLNA V9 V11
2 0020424000 TUBE RING UNIVERSAL (277H-2) @V9 V11
REF 0057106000 TUBE CAGE PRO-TUBE AMPS 230V ONLY
2 0032806000 SCRW TF 6-32x1/4 PHP BLX @ COVER BOX
1 0051155000 SCRW SMB #4 x 3/8 PHP BLX @ REVERB RCA JACKS J2
3 0022293000 WSHR FLAT .473x.750 NI @ PWR SW, HIGH/LOW SW, STNDBY
2 0031153000 WSHR FLAT 3/8 x .614" NI @ SPKR JACKS J11 J12
2 0016436000 WSHR LCK INTL 3/8 x .687 x .035 NI @ SPKR JACKS J11 J12
2 0016352000 NUT HEX 3/8-32 x 3/32 TK NI @ SPKR JACKS J11 J12
2 9904101500 SCRW M 6-32x3/8 PHPS BLX ITLW @V12
5 0053480000 WASHER FLAT .442 X.692 NI @ FX BOARD JACKS
5 0053479000 NUT HEX 7/16 20X1/8 NI @ FX BOARD JACKS
4 0026501000 SCRW C 1/4-20x1/2" HH BLX @ PWR XFMR
4 0028272000 NUT KEP 1/4x20 FOJ @ PWR XFMR
8 0022319000 WSHR FLT 1/4x9/16 NI @ PWR XFMR
4 0026553000 SCRW M 8-32 x 3/8" PHP BLX @ OUTPUT XFMR
4 0022004000 NUT KEPS #8-32 ZINC @ OUTPUT XFMR
6 0038900000 SCRW TF 6-32x1/4 PHP ZI
@ CHASSIS GNDS, CHOKE, REV. XFMR, TUBE
CAGE (QTY 10 ON 230V UNITS)
26 0031184000 SCRW M6-32x1/4 PHPS BLX ITLW @ STANDOFFS
1 0057052000 PCB ASSY PRO/CONCERT REVERB MAIN MAIN PCB ASSY
1 0057108000 PCB ASSY PRO/CONCERT REVERB REAR PANEL FX PCB ASSY'S
REF 0047163000 TUBING SHRINK 1" BLACK @ PWR XFMR PRI. LEADS & V1 V2
REF 0012398000 TUBING, SHRINK 3/16 BLK @ PILOT LIGHT WIRES
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
4 0026566000 CORNER 2 HOLE w/ TAB NI
4 0019276000 GLIDE CAB 1.24 X .335 NI
4 0019275000 INSERT GLIDE CUSHION 1.27 DIA
4 0056482000 MOUNTING PLATE EL COM
