Fender Pro-Reverb - Chassis Assembly

PRO-REVERB AMP
PRINTED CIRCUIT BOARD ASSEMBLY – REAR PANEL (cont)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
11 0025802000 FSTN TAB MALE .250x.032 PCB MT
P102-107 P110-111 P220-222
1 0022546000 FUSE HOLDER PCB MTG UNIVERSAL
F1
1 0022548000 FUSE CARRIER 5mm
@F1
1 0013004000 FUSE TD 20mm X 5mm 250V 100mA
@F1
1 0027413000 HDR .1 CTR 6 CKT SQ PIN P1
5 0051658000 JACK MONO R/A
J3-6 J10
Send Return Preamp out Pwr amp
in Footswitch
3 0026481000 JACK TIP
J7-9
V11 Gnd V9
2 0028039000 LED RED 5x5mm SLB-55VR3 D220 D222
1 0033177000 LED RED/GREEN 5x5mm BI-COLOR
D107
1 0036178000 SPACER LED .5x.1 BRN
@ D107
1 0025941001 RES CF 1/2W 5% 560ohm LL
R123
1 0024997001 RES CF 1/4W 5% 100k LL R57
4 0024937001 RES CF 1/4W 5% 10ohm LL R56 R83 R251-252
1 0024965001 RES CF 1/4W 5% 1k LL R55
1 0025059001 RES CF 1/4W 5% 220k LL R54
2 0024987001 RES CF 1/4W 5% 22k LL
R122 R127
1 0024961001 RES CF 1/4W 5% 470ohm LL
R124
2 0028153001 RES CF 1/4W 5% 75k LL R151-152
2 0024980001 RES CF 1/4W 5% 8.2k LL R48 R59
1 0028029001 RES FILM 1W 5% 1.5k LL R213
4 0027354001 RES FILM 1W 5% 220k LL
R120-121 R125-126
2 0033095001 RES MOX FP 1W 5% 1ohm LL R116-117
1 0028091000 SWITCH PUSH SLFLK
S3 FX Loop
1 0048451000 BUTTON PUSH OFF WHITE @S3
2 0016739003 XSTR NPN 2N4401 TO-92
Q100-101
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
2 0028069000 BUSHING SNAP 3/4x1-1/8 WHT @ PWR XFMR
2 0018022000 BUSHING SNAP 5/16x17/32 BLK @ CHOKE & REV. XFMR
2 0012560000 BUSHING SNAP 5/8x27/32 BLK @ OUTPUT XFMR
1 0036486000 CHOKE
1 0049009000 XFMR OUTPUT PROSONIC
1 0055358000 XFMR POWER SUNN T50C
1 0037099000 XFMR REVERB VIBROVERB/65 DLX REVERB XFMR
2 0036570000 SWITCH TOGGLE DPST W/NUTS PWR SW, STNDBY
1 0021741000 HOLDER DIAL LITE ASSY PILOT @ PILOT LIGHT
1 0031625000 NUT HOLDER PILOT LIGHT 1/16-27 @ PILOT LIGHT
1 0032219000 COLLAR-PILOT LIGHT @ PILOT LIGHT
1 0021642000 PILOT LIGHT #T47 @ PILOT LIGHT
1 0025718000 JEWEL PILOT LITE RED #20 @ PILOT LIGHT
1
1 0047213000 CONNECTOR AC LINE MALE IEC IEC PWR JACK
2 0097360000 NUT HEX 4-40 EX LOCk @ IEC PWR JACK
