Fender Pro-Reverb - Parts List

PRO-REVERB AMP
PARTS LIST
NOTE: SHADED ITEMS ARE FOR REFERENCE ONLY
PRINTED CIRCUIT BOARD ASSEMBLY – MAIN
QTY PART # DESCRIPTION REFERENCE DESIGNATION
REF 0057014000 SVC. DIA., COMB. PRO-TUBE AMPS
1 0057015000 PCB FAB MAIN, PRO-TUBE AMPS
2 0038690001 CAP AE AX 1.0uF 100V 20% C17 C37
4 0025960001 CAP AE AX 22uF 16V 20% C8 C29 C34 C111
3 0024819000 CAP AE AX 22uF 500V +50%-10% C203 C206-207
1 0038693001 CAP AE AX 47uF 16V 20% C1
4 0024820000 CAP AE AX 47uF 350V 20% C201-202 C204-205
2 0028494000 CAP AE RDL 1000uF 35V 20% C212-213
2 0031040000 CAP AE RDL 100uF 100V 20% C208-209
2 0028482003 CAP AE RDL 220uF 50V 20% C210-211
2 0036954003 CAP AE RDL 22uF 63V 20% C33 C216
1 0020883002 CAP CD 10pF 1000V 10% C31
2 0051408003 CAP CD 47pF 500V 5% C7 C101
1 0069724002 CAP CD 100pF 1000V 10% C105
1 0051405003 CAP CD 120pF 500V 5% C19
2 0020917002 CAP CD 250pF 1000V 10% C4 C22
1 0051458003 CAP CD 470pF 500V 10% C32
3 0025951002 CAP CD 750pF 1000V 10% C14 C16 C18
1 0025995002 CAP CD 8200pF 1000V 20% C200
2 0034788003 CAP CD .1uF 50V 20% .15” cut C224-225
3 0027272003 CAP MPF .047uF 63V 10% C218 C220 C223
1 0027280003 CAP MPF .15uF 63V 10% C217
2 0027281003 CAP MPF .22uF 63V 10% C215 C221
2 0027286003 CAP MPF .47uF 63V 10% C219 C222
1 0033477003 CAP MPF .68uF 63V 10% C11
3 0024823000 CAP MPF RDL .01uF 400V 10% C23 C103 C110
6 0024833000 CAP MPF RDL .022uF 400V 10% C3 C9 C12 C21 C108-109
10 0024845000 CAP MPF RDL .047uF 400V 10% C2 C6 C10 C13 C15 C24-25 C30 C116-117
3 0024853000 CAP MPF RDL .1uF 250V 10% C100 C102 C104
7 0024854000 CAP MPF RDL .1uF 400V 10% C5 C20 C36 C112-115
2 0024855000 CAP MPF RDL .1uF 630V 10% C106-107
1 0024876000 CAP MPF RDL .68uF 250V 10% C27
1 0037040002 CAP PFF .0033uF 400V 10% C35
1 0037600000 CONTROL SNAPIN 100k B TAPER
R73 Reverb
2 0041507000 CONTROL SNAPIN 1M 10A TAPER
R12 R37 Ch1volume Ch2volume
3 0047540000 CONTROL SNAPIN 250k 15A TAPER
R10 R17 R35 Ch1bass Gain Ch2bass
2 0037597000 CONTROL SNAPIN 250k 30A TAPER
R9 R34 Ch1treble Ch2treble
1 0041511000 CONTROL SNAPIN 250k B DUAL
R148 Intensity
1 0047031000 CONTROL SNAPIN 25k 30C TAPER
R109 Presence
2 0041510000 CONTROL SNAPIN 25k B TAPER
R11 R36 Ch1mid Ch2mid
1 0037601000 CONTROL SNAPIN 3M 10C TAPER
R141 Speed
16 0026730001 DIODE 1N4006 800V 1A D100-101 D200-207 D210-215
