PRO-REVERB AMP
PRINTED CIRCUIT BOARD ASSEMBLY – MAIN (cont)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
4 0027354001 RES FILM 1W 5% 220k LL R200-201 R203-204
2 0016979001 RES MF 1/4W 1% 215k LL R217 R240
2 0016971001 RES MF 1/4W 1% 33.2k LL R219 R242
2 0017191001 RES MF 1/4W 1% 36.5k LL R221 R244
4 0017372001 RES MF 1/4W 1% 51.1k LL R216 R218 R239 R241
1 0057221000 RES MOX FP 1W 5% 2.2k R66
1 0057222000 RES MOX FP 2W 5% 10k R205
1 0041268001 RES MOX 2W 5% 10k LL R206
2 0041256000 RES WW 5W 10% 470ohm R118-119
2 0029047000 RES WW BT 7W 10% 270ohm R209-210
2 0028091000 SWITCH PUSH SLFLK
S1-2 Bright ChSelect
2 0048451000 BUTTON PUSH OFF WHITE @S1-2
1 0028503000 THERMISTOR 10 ohm 5A C60-11 RT1
2 0014689003 XSTR N-CH JFET J111 TO-92 Q2-3
3 0041465003 XSTR N-CH JFET J113 TO-92 Q1 Q5 Q102
2 0016739003 XSTR NPN 2N4401 TO-92 Q4 Q200
1 0016742003 XSTR PNP 2N4403 TO-92 Q201
8 0051442000 SOCKET TUBE 9 PIN PCB MOUNT @V1-8
2 0057238000 TUBE SOCKET 8 PIN PCB MOUNT @V9 V11
1 0049976000 SWITCH TOGGLE DPST DC W/NUTS
S203 OutputPower
6 0016440000 STNDOFF RND AL 6-32x1x1/4 @V9 V11 V12 (V12 hardware for PCB mtg)
6 0039367000 SCRW M6-32X3/8 PHP SS INTLWSHR @V9 V11 V12 (V12 hardware for PCB mtg)
4 9904101500 SCRW M 6-32x3/8 PHPS BLX ITLW @V9 V11
2 0026459000 WASHER FLAT 6x3/8 ZI @ V12 (V12 hardware for PCB mtg)
1 0037805000 CABLE RIBBON 6 CKT 2-1/4" PW1
PRINTED CIRCUIT BOARD ASSEMBLY – REAR PANEL
QTY PART # DESCRIPTION REFERENCE DESIGNATION
REF 0057014000 SVC. DIA., COMB. PRO-TUBE AMPS
1 0057017000 PCB FAB REAR PANEL, PRO-TUBE AMPS
2 0036954003 CAP AE RDL 22uF 63V 20% C118-119
1 0027286003 CAP MPF .47uF 63V 10% C214
1 0024823000 CAP MPF RDL .01uF 400V 10% C26
1 0024853000 CAP MPF RDL .1uF 250V 10% C28
2 0047540000 CONTROL SNAPIN 250k 15A TAPER
R47 R58
Send Return
2 0026133000 CONTROL TRIM 25k LIN
R149-150
Balance Bias
3 0026730001 DIODE 1N4006 800V 1A
D104-106
2 0006260001 DIODE 1N4448 SIGNAL D218-219
1 0031017001 DIODE ZEN 1N5223B 2.7V 5% LL D221
1 0026000001 FSTN TAB MALE PCB MT .187X.032 P109
