LIFT STANDARD EN 81-20/50
• In case of failure or deactivation of the light curtain, the kinetic energy of the doors must be limited
to 4J. To limit it the lift controller has to activate the slow close input, pin 25, of VF7.
OVERHEATING PROTECTION.
• The internal temperature of the PM motor is measured by the VF7 when the option of “Temperature
measurement” inside the “Programming options” menu is enabled.
DOOR CONTACT.
• A separate monitoring signal is necessary to check that the car door(s) is/are in the closed position.
To comply this point an additional door contact is added, and the signal should be connected to the
lift controller. The maximum contact rating is 2 A 230 V AC.
REFERENCE DATA
Power supply
AC voltage range 230 V AC + 10%, -15%
Frequency supply 50 ~ 60 Hz
Standby power 0,05 A 4 W
Nominal power 0,21 A 20 W
Inverter
Carrier frequency 16 KHz
Frequency range 0,5 ~ 100 Hz
Voltage range 40 ~ 200 V AC III
Maximum output current 4 A
Positional control Quadrature encoder
Inputs
Synchronous permanent
magnet
10 pole
Voltage supply 106 V
Power 94 W
Nominal torque 1,5 N·m
Nominal speed 600 rpm
Thermal class F-155ºC
Inputs
Impedance 20 kΩ
Voltage 12 V DC to 60 V DC
100 V AC to 230 V AC
