PLATINUM PRODUCT LINE.
EXAMPLE 1: INCREMENT OF PL AND HL.
# Model Opening Number of
panels
PL
[mm]
HL [mm] Panel type Fire homologation Moving mass [Kg]
0 Platinum
PM
Side 2 800 2.000 Double skin F.R. E120 56,85
# Concept Multiplier factor
1 Difference from T2 to C2. 0,06
2 Difference of 100 mm in PL. 0,08
3 Difference of 100 mm in HL. 0,07
ANNEX 2
Door to be calculated:
Model Opening Number of panels PL [mm] HL [mm] Panel type Fire protection
40/10 PM Side 2 900 2.100 Metal sheet F.R. E120
Taking as basis(1):
Model Opening Number of panels PL [mm] HL [mm] Panel type Fire
homologation
Moving mass [Kg]
40/10 PM Side 2 800 2.000 Metal sheet F.R. E120 31,93
Calculations:
Difference per
opening
Difference
per
number of
panels
Difference per PL
(each 100 mm)
Difference
per HL
(each 100
mm)
Difference
per panel
type
Difference per
re homologation
SUM Moving mass
There are
equals
There are
equals
31,93 x 0,07(2) =
2,23 Kg
31,93 x
0,03(3) =
0,95 Kg
There are
equals
There are
equals
2,23 + 0,95
= 3,18
31,93 + 3,18 =
35,11 Kg
1. These specications are in the Annex 1.
2. This factor is the increment of 100 mm in PL. There is the number 4 of the second table of 40/10
PM in the Annex 1.
3. This factor is the increment of 100 mm in HL. There is the number 5 of the second table of 40/10
PM in the Annex 1.
