Fermator VF7 User Manual

22
VF7
Outputs
Contacts Switched
R. contact 50 mW
Switch time 5 ms
Output current Maximum 0,15 A
Voltage 230 V AC
Performance
Open speed 0 ~ 1.000 mm/s
Close speed 0 ~ 1.000 mm/s
ANNEX 1
COMPACT PRODUCT LINE.
# Model Opening Number of
panels
PL
[mm]
HL [mm] Panel type Fire homologation Moving mass [Kg]
0 Compact Side 2 800 2.000 Metal sheet F.R. E120 29,46
# Concept Multiplier factor
1 Difference from T2 to C2. 0,02
2 Difference of 100 mm in PL. 0,03
3 Difference of 100 mm in HL. 0,01
4 Difference from F.R. E120 to F.R. EI60. 0,16
5 Difference from F.R. E120 to F.R. EI120. 0,20
6 Difference from F.R. E120 to F.R. EW60. 0,12
7 Difference from F.R. E120 to F.R. E30 Russia. 0,00
8 Difference from F.R. E120 to F.R. EI60 Russia. 0,16
9 Difference from F.R. E120 to F.R. EI60 Ukraine. 0,16
10 Difference from Metal sheet panels to Wien type vision panels. 0,28
11 Difference from Metal sheet panels to Flush big vision panels. 0,23
12 Difference from Metal sheet panels to Full glass in skirting panels. 0,07
13 Difference from Compact to Compact PM model. 0,01
14 Difference from Compact to Compact+ PM 150 model. 0,05
