Fermator VF7 User Manual

25
VF7
Door to be calculated:
Model Opening Number of panels PL [mm] HL [mm] Panel type Fire protection
Premium PM Side 1 800 2.000 Double skin F.R. E120
Taking as basis(1):
Model Opening Number of panels PL [mm] HL [mm] Panel type Fire
homologation
Moving mass [Kg]
Premium PM Side 2 800 2.000 Metal Sheet F.R. E120 36,61
Calculations:
Difference per
opening
Difference
per
number of
panels
Difference per PL
(each 100 mm)
Difference
per HL
(each 100
mm)
Difference
per panel
type
Difference per
re homologation
SUM Moving mass
36,61 x (-0,17) = -6,13 Kg There are
equals
There are
equals
36,61 x
0,12 = 4,39
Kg
There are
equals
4,39 – 6,13 =
-1,74 Kg
36,61 – 1,74 =
34,87 Kg
1. These specications are in the Annex 1.
2. This factor is the difference between T2 (side 2 panels) to T1 (side 1 panel). There is the number 2
of the second table of Premium PM in the Annex 1.
3. This factor is the difference between metal sheet panel and double skin panel. There is the number
11 of the second table of Premium PM in the Annex 1
