Pag 22
Relay Timing:
- lock-release activation (A2)
- auxiliary device activation (A3)
Initially the relays (which will activate the lock-release or the
auxiliary device) are set at 3 seconds.
The activation time can be changed to any value between 00
and 99 seconds or it can also operate in bistable mode (the fi rst
valid code activates the relay and the next one deactivates it):
3 Enter the associated
action:.
0: Button Disabled.
1: Button Enabled. Action,
the door will open. (Relay 1)
2: Button Enabled. Action,
the auxiliary device will be
activated (if exists). (Relay
2)
3: Button Enabled. Action,
the door will open and the
auxiliary device will be ac-
tivated simultaneously.
0, 1, 2 or 3
Bip
(3 x)
Example : Enable exit button
1 to open the door.
1480 A5 1
