TECHNICAL FEATURES
Power Supply: 12 Vdc/Vac.
Operating Temperature: -20º to 55º C.
Capacity: 100 Access Codes Non-Volatile Memory.
Consumption:
* On standby: 40 mA
* With the lock-release relay active: 110 mA
Panel Connectors:
+, -: 12 Vdc Power Supply.
C1, R1: relay output 1 (potential free)
- C1: relay 1 common wire (lock-release).
- R1: Normally open (NA) or normally closed (NC)
contact (based on confi guration).
C2, R2: relay output 2 (potential free)
- C2: relay 2 common wire (lock-release).
- R2: Normally open (NA) or normally closed (NC)
contact (based on confi guration).
A: auxiliary/panic output. Collector Output Open. Maximum
current of 125 mA
