Pag 28
Sequence of codes to be entered:
Code Master
(1480)
+
Example
A5/
A6
+
0: Button Disabled. 1480 A5 0
1: Button Enabled. Lock Release.
(Relay 1)
1480 A5 1
2: Button Enabled. Activate auxi-
liary devices. (Relay 2)
1480 A5 2
3: Button Enabled. Activate door
+ auxiliary device simultaneously
1480 A5 3
A7 +
Allowing User Codes to be Chan-
ged
1480 A7
A8 +
All-Purpose Device Auxiliary Out-
put Confi guration (0, 1, 2, 3, 4, 5
or 6).
1480 A8 1
A9 + Code Master (1480) 1480 A9 1480
