Pag 25
3 Select the option you require:
0: The all purpose output is not used (by
default). The auxiliary output remains de-
activated.
1: Each time a valid code is entered a 1
second pulse will be generated.
2: Every time Relay 1 is activated the all-
purpose device will also activate, and will
remain activated for 5 seconds longer than
the associated device.
3: The all purpose output will switch every
time a valid code is entered.
4: The all purpose output will be activated
and will remain active every time you press
“A” and a valid keypad code, (purpose
output will remain during 1 minute active).
5: The all purpose output activates once 5
erroneous codes are entered in order, and
will remain active for 5 minutes or until a
valid code is entered.
6: The all purpose output activates once
any key is pressed or deactivates after 15
seconds with inactivity.
Bip
(3 x)
Example: Enable auxi-
liary output.
1480 A8 1
