Panel Connectors:
• System connection terminals:
B,B,B: DUOX Bus: power supply, data, audio and video.
C, NO, NC: Relay dry contact (Max 2A@30Vdc).
+12: output12 Vdc-250mA (maximum 500mA for 100 seconds).
BS, -: exit button.
SP, -: door sensor input.
4
Connecteurs platine:
• Bornes de raccordement du système :
B,B : bus DUOX : alimentation, données, audio et video.
C, NO, NC : contact sec de relais (Max 2A@30Vdc).
+12 : sortie 12 Vcc-250mA (maximum 500mA pendant 100 secondes).
BS, - : bouton-poussoir hall d’entrée.
SP, - : entrée capteur de porte.
4
Anschlüsse Türstation:
• Anschlussklemmen des Systems:
B,B: DUOX-Bus: Stromversorgung, Daten, Audio und Video.
C, NO, NC: Relais-Trockenkontakt (max. 2A@30Vdc).
+12: 12 VDC Ausgang - 250mA (Maximum 500mA während 100 Sekunden).
BS, -: Drucktaste Flur
SP, -: Türsensor
4
Conectores de Placa:
• Terminais de ligação do sistema:
B,B:Bus DUOX: alimentação, dados, áudio e video.
C, NO, NC: Contacto seco do relé (Max 2A@30Vdc).
+12: saída12 Vdc- 250mA (máximo 500mA durante 100 seg.)
BS, -: botão do hall de entrada.
SP, -: entrada para sensor de porta.
5
CN2
Conexión pulsadores individuales placa perl continuo Cityline
Individual connection buttons for continuous prole Cityline panel
Connexion boutons-poussoirs individuels platine prol continu Cityline
Anschluss einzelner Taster für Türstation mit durchgehendem Prol Cityline
Ligação de botões individuais a placa de perl contínuo Cityline
6
CN3
Conexión Módulo OneToOne
OneToOne Module Connection
Connexion module OneToOne
Anschluss OneToOne-Modul
Ligação do Módulo OneToOne
