Fermax LOFT COMPACT 4+N COLOUR User Manual

Pag 15
Ct
+
M
V
V
F2
4
3
1
-
F1
2
6
TA
P6P2
Wiring
NOTES:
- A maximum of 100 monitors can be installed on a 4+N system.
- To connect an additional monitor in the same residence a call multiplier must be
added Ref. 2340.
1,2,3,6: common audio wires
4: call wire
+, -: power supply (18 Vdc)
V: live (coaxial - video)
M: mesh (coaxial - video)
Ct: Camera Activation (10 Vdc)
A, +: Call Extension
T, - : Residence Call Button
F1, F2: Additional Functions (negative output «-»)
Maximum current per F1 and F2 buttons: 50mA at 12Vdc
A, +: Call Extension
P1
P1 (T, - ): Residence Call
Button
2 OUTPUTS VIDEO DISTRIBUTOR
DISTRIBUIDOR VIDEO 2 SALIDAS
V
5
V
1
M
+18
75
M
R1
34
+
V
2
REF.2448
6
VM M
(-)
R
6
+
-
43
1
2
CT COAX
Ct
+
M
V
V
F2
4
3
1
-
F1
2
6
TA
P6P2
Call Extension
