Ferno Model 50-E155-E Stretcher Top
5.7 Carrying Handles -
Chair Position
To lift and carry the stretcher top in the chair position:
• The foot-end operator raises and grasps the
handles on the chair legs.
• The head-end operator grasps the crosstube,
(Figure 16), the stretcher-top main frame, or the
leg posts.
An optional stair chair handle kit (not supplied) is
available. See Accessories and Related Products,
page 37.
Figure 16 - Chair Carrying Points
Head-End
Operator Grasps:
• Crosstube
• Main Frame
• Leg Posts
Foot-End
Operator Grasps
Chair Handles
