TECHNICAL DATA AND PERFORMANCES
Frame
1 2
Model
191 221 261 301 351 401
U.M.
Power supply
400 - 3N - 50 400 - 3N - 50 400 - 3N - 50 400 - 3N - 50 400 - 3N - 50 400 - 3N - 50 V-ph-Hz
NOMINAL performances - Base setting up (VB) - Radiant plants
IR
Cooling A35W18 ( source : air in 35°C d.b. / plant : water in 23°C out 18°C )
Cooling capacity 24,6 27,3 31,9 38,1 44,1 49,6
kW
Power input 7,09 7,81 9,11 11,2 12,8 14,6
kW
EER 3,47 3,50 3,50 3,40 3,45 3,40
-
Water flow rate plant side 4259 4723 5513 6595 7625 8604
l/h
Pressure drops plant side 39 47 38 54 46 58
kPa
IP
Cooling A35W18 ( source : air in 35°C d.b. / plant : water in 23°C out 18°C )
Cooling capacity 24,2 26,8 31,3 37,4 43,2 48,7
kW
Power input 7,01 7,73 9,01 11,1 12,7 14,4
kW
EER 3,45 3,47 3,47 3,37 3,40 3,38
-
Water flow rate plant side 4173 4637 5410 6475 7471 8432
l/h
Pressure drops plant side 37 45 37 52 44 56
kPa
Heating A7W35 ( source : air in 7°C d.b. 6°C w.b. / plant : water in 30°C out 35°C )
Heating capacity 21,4 23,8 27,7 33,2 38,4 43,3
kW
Power input 5,48 6,03 7,03 8,71 9,91 11,3
kW
COP 3,91 3,95 3,94 3,81 3,87 3,83
-
Water flow rate plant side 3651 4063 4731 5657 6549 7371
l/h
Pressure drops plant side 29 35 29 40 34 43
kPa
Heating A2W35 ( source : air in 2°C d.b. 1°C w.b. / plant : water in 30°C out 35°C )
Heating capacity 17,8 19,8 23,0 27,5 31,8 35,9
kW
Power input 5,39 5,92 6,90 8,54 9,72 11,1
kW
COP 3,30 3,34 3,33 3,22 3,27 3,23
-
Water flow rate plant side 3034 3377 3926 4697 5434 6120
l/h
Pressure drops plant side 20 25 20 28 24 30
kPa
Data declared according to EN 14511. The values are referred to units without options and accessories.
