Ferroli RMA series User Manual

15
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
15 20 25 30 35 40 45 50
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
15 20 25 30 35 40 45 50
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
15 20 25 30 35 40 45 50
TECHNICAL DATA AND PERFORMANCES
COOLING performances
The graphs allow to get the corrective factors to
be applied to the nominal performances in order
to obtain the real performances in the selected
operating conditions.
The reference nominal condition is :
A35W7
source : air in 35°C d.b.
plant : water in 12°C out 7°C
Outlet temperature
plant side :
A = 24°C
B = 18°C
C = 12°C
D = 7°C
Cooling capacity
Inlet air temperature d.b. [°C]
Inlet air temperature d.b. [°C] Inlet air temperature d.b. [°C]
Power input EER
A
B
C
D
A
B
C
D
A
B
C
D
