18 Festo – CLR – 2017-05e English
13 Technical specifications
CLR-... 12 16 20 25 32 40 50 63
Design Double-acting pneumatic cylinder with swivel
mechanism
Mounting position As desired
Medium Filtered compressed air, lubricated or non-lubricated
(filter fineness 40 μm)
Operating pressure range 2 ... max. 10 bar
Connecting thread M5 G 1/8
Temperature range -10 ... +80 °C (ambient)
-10 ... +50 °C (storage)
Theoretical tension force [N]
Effective tension force [N]
(at 6 bar returning)
51
34
90
53
121
109
227
188
362
313
633
536
990
716
1682
1386
Possible swivel direction L/R L/R/G
(L = left, R = right, G = straight)
Max. perm. work frequency
(at room temperature)
– Linear-swivel movement: 0.8 Hz
– Linear movement: 1 Hz
Max. swivel angle tolerance 90° ±4° 90° ±3° 90° ±2°
Stroke tolerance 0 mm /+2.5 mm
Materials Housing: Al
Piston rod: St (coated with CLR-...-K11-R8)
Collar screws, guide pin: St
Bearings: CuSn
Seals: NBR, TPR
Wiper (with CLR-...-K11-R8): PPS
Weight without clamping
finger [kg] (approx.)
– at 10 mm stroke
– at 20 mm stroke
0.14
0.16
0.16
0.19
0.34
0.39
0.40
0.46
0.69
0.77
0.88
0.99
1.7
2.1
2.1
2.7
