Festo P.BEKCMMP−AS 0708NH Deutsch7
3 Anzeigen und Anschlüsse (CMMP−AS−C2−3A)
CMMP−AS Ansicht oben
1 X9: Versorgung
2 X11: Inkrementalge
berausgang
3 X10: Inkrementalge
bereingang
4 X1: E/A−Schnitt
stelle
CMMP−AS Ansicht unten
5 X2B: Encoderan
schluss
6 X2A: Encoderan
schluss
7 Motoranschluss
CMMP−AS Ansicht vorne
8 Einschubscchte
Ext 1 und Ext 2 für
die Felbusmodule
9 X4: CANBus
aJ X5: RS232/485
aA X3: Steueranschluss
für Treiberversorgung
(Sicherer Halt)
Bei CMMP−AS−...11A
liegt Stecker X3 zwi
schen X5 und der
7−SegmentAnzeige
aB 7−SegmentAnzeige
aC LEDs
1
2
3
4
5
6
7
8
9
aJ
aA
aB
aC
