Festo CMMS-ST-C8-7-G2 Mounting And Installation

2 Produc t overview
Festo – GDCP-CMMS-ST-G2-HW-EN – 1404NH – English 11
2 Product over view
2.1 The entire system for the CMMS-ST-C8-7-G2
1 Power switch
2 Fuse – dependent on 3 and 4
3 24 V power supply unit for control voltage
4 Power supply unit for power supply
5 Motor controller CMMS-ST-C8-7-G2
6 PC with serial c onnecting c able for para-
meterisation and c ommissioning with the
Festo Configuration Tool (FCT), CMMS-ST
plug-in
7 Motor – here EMMS-ST with encoder
(motor and encoder c able NEBM)
5
6
1
2
3
4
7
Fig. 2.1 Complete structure CMMS-ST-C8-7-G2 – example
