2 Produc t overview
Festo – GDCP-CMMS-ST-G2-HW-EN – 1404NH – English 17
S1.9 … 10 ON/OFF (example) Significance
1)
9 ON 1 DIP switch S1.9 is the low-order bit.
00: 125 kBit/s
01: 250 kBit/s (example)
10: 500 kBit/s
11: 1000 kBit/s
10 OFF 0
1) Additional information Description of functions and commissioning, GDCP-CMMS/D-FW-....
Tab. 2.6 CAN-bus transmission rate
2.4.4 Slot [EXT]
The slot ( Fig. 2.2 4 ) enables the option of expanding CMMS-ST-C8-7-G2 by other interfaces, e.g.:
– CAMC-PB: interface for PROF IBUS DP
– CAMC-DN: interface for DeviceNet.
For mounting, please observe the mounting instruct io ns for the CAMC interface. If the
interface is mounted, it is automatically activated the next time the motor c ontroller is
switched on. I nfo r mation a bout function can be found in the FHPP device profile descrip-
tion, GDCP-CMMS/D-C-HP-....
2.4.5 Card s lot [M1] for SD memory card
A parameter set can be loaded from/saved onto the memory card by using the FCT soft-
ware. You can find additional information in the Help file of the CMMP-ST FCT plug-in and
in the functions and commissioning description, G DCP-CMMS/D-FW-....
SD memory card
Description
Functions Copying/loading a parameter set from the memory card to the
CMMS-ST-C8-7-G2.
Copying/saving a parameter set from the CMMS-ST-C8-7-G2 to the
memory card.
Copying (loading) firmware from the memory card to the
CMMS-ST-C8-7-G2 (Bootloader)
Design on the device 1x12-pin S D c ard slot
Supported card types SD
1)
(version 1 and 2)
Supported file systems FA T16
Format filename 8.3
1) Recommended are industry-suitable memory cards from the Festo accessories programme.
Tab. 2.7 Characteristics of the memory card ( Fig. 2.2 5 )
