3 Mechanical installation
20 Festo – GDCP-CMMS-ST-G2-HW-EN – 1404NH – English
Please note
An excessive temperature increase results in premature aging or damage to the motor
controller.
• Observe t he specified installation clearances to ensure sufficient ventilation
( Tab. 3.2).
CMMS-ST
H1
1)
L1 L2
– Installation c learance [mm] 100 69 9
1) Recommendation for optimum wiring of the motor and encoder cable: Installation clearance H1 at the bottom = 150 mm.
Tab. 3.2 Installation clearance CMMS-ST
3.3 Di sassembly
Caution
Motor controller contains condensers (energy storage)
Do not disconnect connecting cables when powered. Before mounting and installation
work:
1. Switch off power to the electrical equipment via the mains switch and secure it
against being switched on again.
2. After switch-off, wait at least 1 minute discharge time and chec k that power is
turned off before accessing the controller.
Caution
Danger of burns from hot surfaces
Dependent on t he load of the motor controller, housing temperatures > 80 ° C are pos-
sible in operation.
• Touch them only in a switched-off, cooled-off status.
