Removing:
S Remove the screws and lift the CMAX carefully.
Mounting:
1. Check the seal and sealing surfaces and refit the
sub-base.
2. Screws must be fitted so that the self-cutting threads
can be used. Tighten the screws by hand in diagonally
opposite sequence. Tightening torque 0.9 … 1.1 Nm.
3.3 Pin assignment of axis connection
X
Pin Assignment
1
2
3
4
5
Housing
+24 V logic voltage
+24 V load voltage
0 V
CAN_H
CAN_L
Cable shield
