Exercise 1
Constructing a stepper motor system
Learning objectives
After completing this exercise:
• You will be familiar with the safe design or assembly of a stepper motor system
• You will be familiar with the basic principles of connection technology and circuit technology of the
components used
Problem description
A stepper motor system is to be constructed using individual components. To do this, the motor controller,
stepper motor, rotary drive, signal input and proximity sensor must be correctly connected or linked in order
to obtain a reliable, complete system.
Positional sketch
Stepper motor system
