4 Technical data
Cordless sliding table
saw
CSC SYS 50
Motor voltage 36 V
Speed (no-load) 6800 rpm
Suitable battery packs
Festool series
BP 18 ≥ 4 Ah
Locating bore Dia. 20 mm
Bevel angle -10–47°
Cutting height at 0°
0–48 mm
*
Cutting height at 45°
0–34 mm
*
Cutting height at 47°
0–33 mm
*
Cutting height at ‑2°
0–48 mm
*
Cutting height at ‑10°
21–32 mm
*
Cross cut width at 90° 450 mm
Cross cut width at 45° 340 mm
Cross cut width at 70° 140 mm
Parallel cut width 280 mm
Mitre angle 0–70°
Transport dimensions 512 x 396 x
296 mm
Table height 228 mm
Frequency 2402–2480 MHz
Equivalent Isotropically
Radiated Power (EIRP)
< 10 dBm
Total weight without bat
tery packs
20.2 kg
* Due to manufacturing tolerances of saw blade and power tool, higher
cuts may also be possible.
5 Parts of the device
The illustrations specified are located at the be
ginning and end of the operating instructions.
[1-1]
Gripping surface
[1-2]
Cooling air opening
[1-3]
Main switch
[1-4]
Status LED
[1-5]
Clamp lever to fix the preset profile
setting rail
[1-6]
Sliding table
[1-7]
Groove for preset profile setting rail
[1-8]
Groove for Festool guide rail clamp
[1-9]
Table insert
[1-10]
Hexagon socket wrench
[1-11]
Non-through cutting spacer wedge
[1-12]
Spacer wedge with protective cover
[1-13]
Push stick in push stick holder
[1-14]
Parallel side fence
[1-15]
Cutting width scale for rip cutting
[1-16]
Extension table
[1-17]
Extension table locking mechanism
[1-18]
Control module
[1-19]
Dust collection bag
[1-20]
Preset profile setting rail
[1-21]
Sliding table locking lever
[1-22]
Locking clip
[1-23]
Systainer hood
[1-24]
Carrying handle
6 Control module
6.1 Elements of the control module
[2-1]
Angle button
[2-2]
Height button
[2-3]
Display
[2-4]
Dial
[2-5]
Start switch
[2-6]
Stop switch
6.2 Display elements
Depending on the context, different elements
are shown on the display [2-3].
[2-7]
Position on page X of Y (for assis
tants)
[2-8]
Info graphic dialogue box
[2-9]
Info text dialogue box
[2-10]
Focus line option
[2-11]
Favourite parked position
[2-12]
Cutting angle (main screen)
[2-13]
Cutting height (main screen)
[2-14]
Battery pack capacity indicator
English
31

Festool CSC SYS 50 EBI Specifications

General

Brand	Festool
Model	CSC SYS 50 EBI
Category	Saw
Language	English
