► Unlock and swivel the saw blade flap [15-1]
downwards.
► CAUTION! Wear protective gloves.
Remove any remaining parts of the work
piece and use an extractor in the area
around the saw blade.
► Close the saw blade flap and fit the cover
plate.
► Insert the hex key into the holder [1-10]
provided.
11 Transportation
CAUTION
Risk of injury!
The power tool may slip out of your hands
when you are carrying it.
► Always carry the power tool with both
hands, using the gripping surfaces [1-1]
provided on both sides of the power tool.
► When carrying with the carrying han
dle [1-24], ensure that the lid is secured
with both locking clips.
CAUTION
Risk of injury
The sliding table may extend. The extension
table may unfold.
► The power tool must always be transported
in the transport position that has been pro
vided for this purpose.
11.1 Securing the power tool (transport
position)
► Move the saw blade to the parked position
with the control module (select favourite
"P").
► Use the main switch to switch off the power
tool (see section 7.3
).
► Lock the sliding table in position (see sec
tion 9.13).
► Fold the extension table (see section 9.11).
► Push the stop rails together until the two
adjustment markings for the parked posi
tion (see section 1) are facing each other.
► Put the parallel side fence on the power tool
in parked position [16B].
► Stow the spacer wedge with protective cov
er and the remaining accessories in the
lid [16A]
. The preset profile setting rail can
also be attached to the power tool in parked
position [16B]
.
► Close the lid and secure it with the two
locking clips.
The power tool is in the transport position.
12 Service and maintenance
WARNING
Risk of injury, electric shock
► Always remove the battery pack from the
power tool before performing any mainte
nance or service work.
► All maintenance and repair work which re
quires the motor housing to be opened
should always be carried out by an author
ised service workshop.
Customer service and repairs
must
only be carried out by the manufac
turer or service workshops. Find the
nearest address at:
www.festool.co.uk/service
Always use original Festool spare
parts. Order no. at:
www.festool.co.uk/service
► Damaged safety devices and components
must be repaired or replaced in a recog
nised specialist workshop, unless otherwise
indicated in the operating instructions.
► To ensure constant air circulation, always
keep the cooling air openings in the housing
clean and free of blockages.
► Use an extractor to remove dust deposits,
splinters and chips (see section 10.8).
12.1 Adjusting the extension table height
► Image [17]
12.2 Adjusting the sliding table height [18]
If the height of the sliding table no longer
matches the height of the plate:
► Move the sliding table into the front posi
tion.
► Remove the cover cap [18-1] and undo the
screw underneath it.
► Move the sliding table into the back posi
tion.
► Remove the cover cap [18-2] and undo the
screw.
► Adjust the height of the sliding table with
the adjusting screws [18-3]
and [18-4].
Turn to the right = lower
Turn to the left = lift
► Tighten the screws [18-1]
and [18-2]
(3.5 Nm) and fit the cover caps.
English
38
