Independent extraction
► Secure the connection piece [5-1] of the
dust collection bag [5-3] at the extractor
connector [5-2] with a clockwise rotation.
► To empty, remove the connection piece of
the dust collection bag from the extractor
connector with an anti-clockwise rotation.
Blockages in the guard may impair safety fea
tures. To avoid blockages, it is therefore better
to work with a mobile dust extractor at full suc
tion power.
Static charge may occur when sawing (e.g.
MDF). If this is the case, work with a mobile
dust extractor and an antistatic suction hose.
Festool mobile dust extractor
A Festool mobile dust extractor with a suction
hose diameter of 27 mm can be connected at
the extractor connector [5-2]
.
The adapter on a suction hose is inserted into
the adapter [5-2].
CAUTION!
If an anti-static suction hose is not
used, static charge may occur. The user may
receive an electric shock and the electronics of
the power tool may be damaged.
9.11 Extension table
[6]
To extend the working surface for rip cutting
from approx. 95 mm
.
►
Unfold the extension table.
► Fold the extension table.
9.12 Parallel side fence
Fitting the parallel side fence
► Image [7]
Setting the cutting width for rip cutting
► Image [8]
Adjusting the stop rail [9-1]
► Image [9A]
Rotate
[9B] the stop rail [9-1] for angled
cuts or very small workpieces. The lower
side then points towards the saw blade.
9.13 Adjusting the sliding table
The sliding table can be secured in two posi
tions.
Working position
► Rearmost position A, image [10]
Saw blade change position
► Foremost position B, image [10]
CAUTION!
Risk of injury. Always secure the
sliding table while it is not used for sliding.
9.14 Preset profile setting rail
The preset profile setting rail can be set as a
cross stop or angle stop (mitre fence).
WARNING
Risk of accidents due to tools
► The stop rail [13-1] must not protrude into
the cutting areas.
► All screws and rotary knobs of the preset
profile setting rail must be firmly tightened
when sawing.
Fitting/removing the preset profile setting rail
► Image [11]
Setting the angle
► Image [12]
The preset profile setting rail engages at 13
commonly used angle settings.
Adjusting the stop rail side position
► Image [13]
9.15 Selecting the saw blade
Festool saw blades are identified by a coloured
ring. The colour of the ring represents the ma
terial for which the saw blade is suited.
Refer to the necessary saw blade data (see sec
tion 3.1).
Colour Material Symbol
Yellow Wood
Red Laminate, mineral ma
terial
HPL/TRESPA
®
Blue Aluminium, plastic
"$3:-
9.16 Changing the saw blade
WARNING
Risk of injury
► Switch the power tool off at the main
switch and remove the battery pack from
the power tool before performing any work
on the power tool.
English
35
