9.6 Adjusting the cutting angle
CAUTION
Risk of crushing
When adjusting the cutting angle, the extrac
tion channel also moves.
► Do not place hands or objects between the
extraction channel and sliding table.
Adjust the cutting angle using the control mod
ule.
► Press the angle button [2-1].
► Set the desired angle on the dial [2-4] with
in ten seconds.
To end setting mode early, before ten sec
onds have passed: Press the angle button.
Adjusting the cutting angle in tenths:
Press the dial while turning it.
9.7 Calibrating the cutting angle
If the saw no longer cuts correctly at the cutting
angle that has been entered:
► Calibrate the cutting angle using the assis
tant on the control module.
9.8 Favourites
Four commonly used combinations of cutting
height and cutting angle can be saved as fa
vourites. A fifth favourite "P", which cannot be
changed, is the parked position. This is only
shown if the Systainer hood cannot be put on in
the current position.
Selecting a favourite
► Select a pair of favourites [2-11] on the
main screen with the dial.
► Press and hold the dial until the saw blade
position has been fully reached.
Saving favourites
► Set the desired combination of cutting
height and cutting angle.
► Press the angle button and height button at
the same time.
► Select the required favourite position [2-11]
with the dial.
► Confirm your selection by pressing the dial.
9.9 Spacer wedge
WARNING
Risk of injury
► Switch the power tool off at the main
switch and remove the battery pack from
the power tool before performing any work
on the power tool.
WARNING
Risk of injury
► Never work without a spacer wedge.
Spacer wedge with guard [1-12]
Where possible, always use the spacer wedge
with guard.
Non-through cutting spacer wedge
[1-11]
For hidden cuts or grooves.
Removing the spacer wedge, option 1 [4A]
►
Move the saw blade to the parked posi
tion with the control module (select favour
ite "P").
► Press a hex key [1-10] into the opening
on the type plate, hold it there and pull the
spacer wedge upwards to remove it.
►
Place the hex key into the holder [1-10]
provided again.
Removing the spacer wedge, option 2 [4B]
► Remove the cover plate (see section 9.16
).
►
Press and hold the spacer wedge locking
mechanism and pull the spacer wedge up
wards to remove it.
► Fit the cover plate again.
Fitting the spacer wedge [4C]
► Push the spacer wedge in from above until
it engages. WARNING! Risk of injury! Check
that the spacer wedge has engaged proper
ly.
9.10 Dust extraction
WARNING
Health hazard posed by dust
► Always work with an extractor.
► Comply with national regulations.
► When sawing carcinogenic materials, al
ways connect a suitable extraction mobile
in accordance with national regulations. Do
not use the chip collection bag.
English
34
