Festool DOMINO User Manual

3 4
51 2
4746
4
Use this method to carry out routing for all four frame rails,
whereby every second frame rail is routed into the workpiece
lengthwise instead of into the front.
Then glue the frame rail and brace with pads and clamps,
if necessary.
The second routed hole is set here using the stop catch.
This method makes it possible to position two dominos next
to each other working from just one reference edge.
TIP When using the stop catches, the edge of the work-
piece can be seen in the triangular viewing window of the
DOMINO joining machine.
TIP If the frame rail needs to be rebated or grooved, the
rebating depth must be added in advance when routing
the domino holes, so that the domino is centred later despite
the rebate (which then takes up part of the depth of the
domino hole).
2016_FES_DOMINO_Book_GB-en.indb 47 03.03.16 12:13

Festool DOMINO Specifications

General

Motor Power	420 W
Dust Extraction Connection Diameter	27 mm
Power Source	Corded Electric
Cutting Depth	15 mm, 20 mm, 25 mm, 28 mm
Cutter Diameter	5 mm, 6 mm, 8 mm, 10 mm
