Festool DOMINO User Manual

5554
4
Set the routing height to the centre of the workpiece. Mark
out the axis distance of the spindles on the top side of the
workpiece. In this case (when simply using markings) bring
the scale in the viewing window of the DOMINO over the
scribe mark and set the routed holes. A second scribe mark,
as in the example of the handrail above, is not necessary here.
TIP For workpieces where a secure support surface is
possible for the joining machine, simply marking out the
domino holes or central axis of the spindles is sufficient
(in this case you do not have to work with the trim stop).
TIP Of course, bevelled joints are also possible with
spindles needed especially for going up and down stairs.
In this case, set the cutting angle of the spindle on the
DOMINO joining machine during routing (using the routing
angle adjustment) and route the domino hole.
Set the routed holes in the handrail as described above.
Then join the spindle and handrail together.
2016_FES_DOMINO_Book_GB-en.indb 54 03.03.16 12:13

Festool DOMINO Specifications

General

Motor Power	420 W
Dust Extraction Connection Diameter	27 mm
Power Source	Corded Electric
Cutting Depth	15 mm, 20 mm, 25 mm, 28 mm
Cutter Diameter	5 mm, 6 mm, 8 mm, 10 mm
