Push both workpieces together ...
... and clamp the connectors by tightening the stud on the
second workpiece side.
TIP In general, these connections are located on the
bottom of tabletops and kitchen worktops, i.e. outside
of visible area. Nevertheless it is possible, of course, to
cover the transverse holes with cover caps.
... and tighten the stud in the first transverse anchor.
Then push the double-headed bolt into the workpiece ...
2016_FES_DOMINO_Book_GB-en.indb 73 03.03.16 12:13

Festool DOMINO Specifications

General

Motor Power	420 W
Dust Extraction Connection Diameter	27 mm
Power Source	Corded Electric
Cutting Depth	15 mm, 20 mm, 25 mm, 28 mm
Cutter Diameter	5 mm, 6 mm, 8 mm, 10 mm
