After routing the first hole (the pin is positioned at the edge of
the workpiece in this case), the pin goes into the routed hole,
thus setting the next stop. Route the first hole with precision,
and all other holes as slots with clearance.
Then join the workpiece parts together, gluing the dominos
carefully in the process.
TIP For larger hole distances, you can work with the cross
stop (available as an accessory or included in the DF 500 set)
both with the DF 500 and the DF 700.
Use the stop pin system to select the hole distance based on
the individual workpiece. In this example, we are working with
the two centre pins, to create a hole distance of 37 mm.
