Go to fetco.com for the latest versions of all information Page 15 P167 March 2018
Ref
Qty
Part Number
Description Drawing 1101.00342.00 CBS-1151XV+
1
1
1111.00088.00
WELDMENT, COMPLETE, CBS-1151 XV+
2
1
1057.00043.00
SOLENOID VALVE, 5.5L/min, 180 DEG, 24VDC
3
2
1083.00005.00
LOCKWASHER, M4 18-8 INTERNAL TOOTH
4
2
082.00010.00
SCREW, M4x10 ZINC-PLATED PAN HD. PHILLIPS MACHINE.
5
1
1102.00243.00
ADAPTER ASSY, 3/4" BSP x 1/4" NPT x 3/8" TUBE
6
8
1081.00006.00
SPACER, 6MM OD x 3.2MM ID x 5MM LG
7
1
1052.00001.00
POWER SUPPLY, 90-264VAC/24VDC, 1.8A
8
4
1029.00012.00
SPACER, .25" HEX X 1" LG, FEM #4-40 THREAD
9
1
1112.00268.00
WELDMENT, BRACKET TERMINAL BLOCK, 4 POLE
10
5
1083.00011.00
INTERNAL TOOTH LOCKWASHER, #8 SCREW SIZE,
11
13
1084.00006.00
NUT, 8-32 18-8 HEX MACHINE SCREW
12
1
1052.00023.00
EUROSTRIP HE16 TERMINAL BLOCK, 4 POLE, 63 AMP, 18-8 AWG
13
1
1052.00025.00
MARKING PLATE
14
2
1082.00082.00
SCREW, PHILLIP HD., 8-32 THREAD
15
1
1065.00009.00
GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
16
1
1044.00012.00
LABEL GROUND, CE
17
1
1058.00024.00
SWITCH, POWER, DOUBLE POLE, 16A, 125/250 VAC
18
1
1046.00051.00
LABEL, "WARNING, EXTREMELY HOT WATER"
19
1
1071.00055.00
FAUCET, HOT WATER, PSC-BR-8, WITH FLAT AND STEM
20
1
1084.00048.00
JAM NUT, 1/2-20 UNF, NICKEL PLATED BRASS
21
1
1102.00375.00
ASSEMBLY, FRONT PANEL, CBS-1100 SINGLE
22
1
1083.00009.00
LOCKWASHER, #6 SCREW , INTERNAL TOOTH
23
1
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
24
1
1102.00223.01
SPRAY HOUSING, LARGE, 24 VDC, X
25
6
1083.00010.00
WASHER, #10 SCREW W/NEOPRENE-BONDED SEAL
26
1
1025.00021.00
TUBE, 31/32"OD X 5/8"ID X 4 1/4"LG, BREW
27
1
1086.00018.00
HEYCO HOSE CLAMP DIA. .875-1.00
28
1
1086.00017.00
HEYCO HOSE CLAMP DIA .1.031-1.187
29
1
1102.00113.00
SWITCH, REED, ASSEMBLY
30
1
1029.00006.00
NUT, FINGER, #4-40 NYLON
31
1
1025.00082.00
TUBE, 5/8"OD X 3/8"ID X 19.00"LG.
32
4
1086.00003.00
UNICLAMP, 15.9 HOSE OD CLAMP
33
1
1025.00058.00
TUBE, 9/16"OD X 5/16"ID X 25.00"LG
34
1
1086.00009.00
CLAMP, 3/4" MAX TUBE OD FLOW CONTROL
35
11
1084.00011.00
NUT, CLIP ON (J-NUT), #6-32, 22-20 GA.
36
1
1001.00362.00
COVER, TOP, CBS-1151
37
12
1082.00017.00
SCREW, TRUSS HD. PHIL. MACHINE, # 6-32 X 1/2 LG.
38
1
1001.00363.00
COVER, UPPER BASE, CBS-1151 XV+
39
1
1402.00097.01
HARNESS, LOW AMP, CBS-1151-XV+, UL
39
1
1402.00061.01
HARNESS HIGH AMP
39
1
1402.00050.01
HARNESS HIGH AMP CE
40
1
1112.00470.00
WELDMENT, RIGHT COVER, CBS-1150 XV+
41
1
1024.00098.00
VENT TUBE, XTS & XV+
42
1
1058.00055.00
USB CONNECTOR
43
1
1084.00024.00
NUT, CLIP ON (J-NUT), #6-32, 1050
44
1
1046.00035.00
LABEL, WARNING "TO REDUCE RISK OF ELECTRIC SHOCK OR FIRE"
45
1
1041.00031.00
LABEL, XV+ LOGO
46
1
1046.00003.00
LABEL, CSD WARNING, 1.5" X 5.0"
47
1
1052.00036.00
EMI FILTER
48
1
1086.00008.00
CORD STRAIN RELIEF-UL MODELS
48
1
1086.00031.00
CORD STRAIN RELIEF CE MODELS
49
4
1073.00007.00
LEG-FLANGE FOOT
50
1
B015280BN2
BREW BASKET-PLASTIC-STANDARD
50
1
B001280B1
BREW BASKET-STAINLESS STEEL- (OPTIONAL)
51
1
1104.00061.01
TANK ASSEMBLY, CBS1151 XV+ 2 X 3KW/240VAC
51
1
1104.00095.01
TANK ASSEMBLY, CBS1151 XV+ 5KW/240VAC
51
1
1104.00096.01
TANK ASSEMBLY, CBS1151 XV+ 2 X 2.3KW/240VAC
51
1
1104.00097.01
TANK ASSEMBLY, CBS1151 XV+ 4KW/240VAC
