Fetco CBS-1150 EXTRACTOR V+ - C Inputs; D Outputs; E Other

Go to fetco.com for the latest versions of all information Page 8 P167 March 2018
D OUTPUTS
Test Valves and Heaters; Set screen brightness
POSITION Program Items Factory set Default
Programming
Range
Increments Notes
D1
Heater Test
Press button 2 to test
(button 1 stops test)
Activates valve
Default is 10 sec..
Toggle +/-
OFF or ON
Energizes Heater(s)
WARNING! Service use
only.
D2
Fill Valve Test
Press button 2 to test
(button 1 stops test)
Activates valve
Default is 10 sec.
Toggle +/-
OFF or ON
Press To Test
D3
Left Valve Test
Press button 2 to test
(button 1 stops test)
Activates valve
Default is 10 sec.
Toggle +/-
OFF or ON
Runs valve to verify flow.
NOTE: Have container
under brew basket.
Single series displays LEFT side only RIGHT Valve display is only for CBS-1152 XV+ twin side brewer.
D4
Right Valve
Test
Press button 2 to test
(button 1 stops test)
Activates valve
Default is 10 sec.
Toggle +/-
OFF or ON
Press To Test
D7 LCD Brightness Brightness=8 0-15 1
Adjust LCD screen
brightness only-Not for
LEDs under buttons
.
C INPUTS
Brewer Sensors and Keypad
POSITION Program Items Factory set Default Programming Range Increments Notes
C1
LLC Probe
Continuity
Direct read
Reading of tank water
resistivity in TDS
≈850- LOW
≈1600-HIGH
Nominal values
C2
Brew Basket
Sensor
Direct read YES or NO
C3 Tank Temperature Direct read
Hot water tank
temperature
Actual values
C4 Keyboard Test Calibrate
Checks buttons under
membrane cover
YES/NO
Follow directions
on the touch
screen
E OTHER
Software & Code View and Settings
POSITION
Program Items
Factory set Default
Programming Range
Increments
Notes
E1 Display Firmware
1.0.1744
Displays current
version
E2 Select Model
CBS-1151 XV+ OR
CBS-1152 XV+
Will need reboot
Scroll to brewer
model Save&Exit
CBS_1131;
CBS_1132;
CBS_1151;
CBS_1152
NOTE: Overwrites
all user settings
(See page 9)
E3 Display Errors
Lists up to six
codes, in order
1: ; 2: ;3:;4: ;5: ;6:
1=Newest/6=Oldest
LAST six errors only
Newest=last
Oldest=first
See Error Code
Chart for references
E4
Reset Errors
FACTORY USE ONLY
NO +
Toggle +/-
YES or NO
NOTE: Always contact
FETCO Technical Service
for errors (800)338-2699
Resetting error codes should be after completing the service and factory diagnostics and correcting any brewer faults
NOTE Clear error codes by cycling the brewer “OFF” then “ON”. See Page 9.
E5
(Reload) DEFAULTS
Reset to default of
base model
Will need reboot
Toggle +/-
YES or NO
COMPLETELY
OVERWRITES ALL
USER SETTINGS
E6
USB Data Save
Save data to USB
E7 Load From USB
Plug in USB flash-
drive device.
Will need reboot
E8 DEMO Mode DEMO ON/OFF Will need reboot
Demonstrates the controls
for training. Brewer will not
brew when in demo mode.
Reset in E8 to “OFF” to exit
