Fetco CBS-1150 EXTRACTOR V+ - General Brewer Settings; B GENERAL Settings

Go to fetco.com for the latest versions of all information Page 7 P167 March 2018
B GENERAL
Brewer Operation Control Settings, Adjust Brew Flow Rate
POSITION Program Items Factory set Default
Programming
Range
Increments Notes
B1 Tank Temp.
93° C -or- 200°F
NOTE: Equipment
is metric by default
70° to 96°C
157°F to 205°F
0.5°C
1.0°F
See below
for chart to correct
for high altitude
B2
Brew at Temp.
“YES”
ON/OFF
YES/NO
SEE NOTE BELOW
B3 LLC Sensitivity LOW
LOW is “normal”
for most water
“HIGH” for R.O.
LOW
or
HIGH
Liquid level control
sensitivity.
High,1300Ω is for
reverse osmosis water
or very pure water.
B4
Temperature
Scale
°F Fahrenheit
Celsius
Fahrenheit
C/F
NOTE: Overwrites
user settings (see page 9)
B5 Volume Scale G Gallons Gallons/Liters L/Gal
NOTE: Overwrites
user settings (see page 9)
B6
LEFT brew valve
F.R. is in
Liters/Min
CBS-1152
3.40L/0.9G
2.9-3.9Liter 0.73-
1.01Gallon
0.50L
0.01Gal
Adjusts flow rate
B7
RIGHT brew valve
F.R. is in
Liters/Min
CBS-1151&1152
3.40L/0.9G
2.9-3.9Liter 0.73-
1.01Gallon
0.50L
0.01Gal
Adjusts flow rate
B10
Low flow rate
from mains
NO OFF/ON
Toggle +/-
YES or NO
Trims fill system for
low supply
Use this formula to compensate for minor discrepancies in actual volume versus programmed volume
Measured Volume
X
Current
Setting
=
New
Setting
Use this formula to determine flow rate to compensate for
minor discrepancies in actual volume versus programmed
volume. Enter new setting in B6 or B7
Programmed Volume
Use the formula above to compensate and fine-tune brew volume. Brew valve and bypass valve flow rates are in liter/min.
Enter the brew valve New Setting value into B6/B7 and save as in the “F” screen (Brew volume is set at position A11)
HINT: Set lower to increase volume, higher to decrease volume. TIP: Always check flow from supply for fouled water filter
BREW AT TEMPERATURE DEFINITIONS
Chart to correct for altitude for boiling point
in tank water temperature.
[ft] [m]
Suggested
Setting[°F]
Boiling
point[°F]
Suggested
Setting[°C]
Boiling
point [°C]
0
0
205
212.0
96
100.0
500
152
205
211.0
96
99.5
1000
305
200
210.1
93
98.9
2000
610
200
208.1
93
97.8
2500
762
200
207.2
93
97.3
3000
914
200
206.2
93
96.8
3500
1067
197
205.3
92
96.3
4000
1219
195
204.3
91
95.7
4500
1372
194
203.4
90
95.2
5000
1524
194
202.4
90
94.7
5500
1676
193
201.5
89
94.2
6000
1829
192
200.6
89
93.6
6500
1981
191
199.6
88
93.1
7000
2134
190
198.7
87
92.6
7500
2286
188
197.8
86
92.1
8000
2438
187
196.9
86
91.6
8500
2591
185
196.0
85
91.1
DEFAULT: BREW AT TEMP: “ON”
(FACTORY DEFAULT FOR BREWER)
“BREW at TEMP:
-Batch will not start if tank temperature
is below set point.
-Display will show “HEATING”
and hot water tank temperature
The “BREW START” entry buttons will not
illuminate until the hot water tank reaches the
selected temperature.
Controls allow both sides of dual brewer to
operate if one side has an ongoing brew
started and the second side brew is selected.
Notifications shown on screen:
TEXT: HEATINGTank above 87°C/189°F-
will allow brew at low temperature.
Coffee flavor may be affected
TEXT: L. HEATTank above 76°C/169°F-
will allow brew at low temperature.
Coffee flavor will be noticeably affected
Hot water tank not at
brew temp setpoint.
Tank temp

STOP is not lit

BREW START
buttons not lit.
and are disabled
.
Buttons will
illuminate “READY”
when
hot water tank
temperature is at
setpoint
vv
vv
vv
HEATING
160°F
USER SELECTABLE OPTION: BREW AT TEMP: OFF
(Not recommended) Unit will operate at cold temperature
Allows brewing at any temperature above 77°C/170°F
Below 70°C/170°F-the red colored ready lights switch turn off
STOP STOP
