Go to fetco.com for the latest versions of all information Page 17 P167 March 2018
Ref
Qty
Part Number
Description Drawing 1101.00339.00 CBS-1152 XV+
1
1
1111.00086.00
WELDMENT BODY COMPLETE, CBS-1152 XV+
2
1
1057.00043.00
SOLENOID VALVE, 5.5L/MIN, 180 DEG, 24VDC
3
2
1083.00005.00
LOCKWASHER, M4 18-8 INTERNAL TOOTH
4
2
1082.00010.00
SCREW, M4X10 ZINC-PLATED PAN HD. PHILLIPS MACHINE.
5
1
1102.00243.00
ADAPTER ASSY, 3/4" BSP X 1/4" NPT X 3/8" TUBE
6
1
1065.00009.00
GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
7
5
1083.00011.00
LOCKWASHER, #8 SCREW SIZE, INTERNAL TOOTH
8
19
1084.00006.00
NUT, 8-32 18-8 HEX MACHINE SCREW
9
1
1044.00012.00
LABEL GROUND, CE
10
1
1058.00024.00
SWITCH, POWER, DOUBLE POLE, 16A, 125/250 VAC
11
1
1058.00055.00
USB CONNECTOR
12
8
1081.00006.00
SPACER, 6MM OD X 3.2MM ID X 5MM LG
13
1
1052.00001.00
POWER SUPPLY, 90-264VAC/24VDC, 1.8A
14
4
1029.00012.00
SPACER, .25" HEX X 1" LG, FEM #4-40 THREAD
15
1
1112.00268.00
WELDMENT, BRACKET TERMINAL BLOCK, 4 POLE
16
1
1102.00284.00
ASSEMBLY, TERMINAL BRACKET INTERNATIONAL VERSION
16
1
1052.00023.00
EUROSTRIP HE16 TERMINAL BLOCK, 4 POLE, 63 AMP, 18-8 AWG
17
1
1052.00025.00
PLATE, MARKING #BS1016E
18
2
1082.00082.00
SCREW, PHILLIP HD., 8-32 THREAD
19
2
1102.00223.01
SPRAY HOUSING, LARGE, 24 VDC
20
12
1083.00010.00
WASHER, #10 SCREW W/NEOPRENE-BONDED SEAL
21
2
1102.00113.00
SWITCH, REED, ASSEMBLY
22
4
1029.00006.00
NUT, FINGER, #4-40 NYLON
23
1
1102.00372.00
ASSEMBLY, FRONT PANEL, CBS-1100 TWIN
24
1
1046.00051.00"
LABEL, "WARNING, EXTREMELY HOT WATER
25
1
1071.00055.00
FAUCET, HOT WATER, PSC-BR-8, WITH FLAT AND STEM
26
1
1084.00048.00
JAM NUT, 1/2-20 UNF, NICKEL PLATED BRASS
27
2
1025.00021.00
TUBE, 31/32"OD X 5/8"ID X 4 1/4"LG, BREW
28
2
1086.00018.00
HEYCO HOSE CLAMP DIA. .875-1.00
29
2
1086.00017.00
HEYCO HOSE CLAMP DIA .1.031-1.187
30
1
1025.00082.00
TUBE, 5/8"OD X 3/8"ID X 19.00"LG.
31
4
1086.00003.00
UNICLAMP, 15.9 HOSE OD CLAMP
32
1
1025.00058.00
TUBE, 9/16"OD X 5/16"ID X 25.00"LG
33
1
1086.00009.00
CLAMP, 3/4" MAX TUBE OD FLOW CONTROL
34
11
1084.00011.00
NUT, CLIP ON (J-NUT), #6-32, 22-20 GA
35
1
1001.00372.00
COVER, TOP, CBS-1152 XV+
36
12
1082.00017.00
SCREW, TRUSS HD. PHILLIPS HEAD. MACHINE, # 6-32 X 1/2 LG.
37
1
1001.00352.00
COVER, UPPER BASE, CBS-1152 XV+
38
1
1402.00053.01
HARNESS, HIGH AMP, CBS-1151-XV+, UL
38
1
1402.00052.01
HARNESS, HIGH AMP, CBS-1151-XV+, UL CE ONLY
38
1
1402.00097.01
HARNESS, LOW AMP, CBS-1151-XV+, UL
39
1
1402.00097.02
HARNESS ADDITION, LOW AMP, CBS-1152-XV+, UL
40
1
1112.00470.00
WELDMENT, RIGHT COVER, CBS-1150 XV+
41
2
1046.00003.00
LABEL, CSD WARNING, 1.5" X 5.0"
42
2
1024.00098.00
VENT TUBE, XTS AND XV+
43
1
1084.00024.00.
NUT, CLIP ON (J-NUT), #6-32
44
1
1046.00035.00
LABEL, WARNING "TO REDUCE RISK OF ELECTRIC SHOCK OR FIRE"
45
1
1041.00031.00
LABEL, XV+ LOGO
46
1
1052.00036.00
EMI FILTER
47
1
1086.00008.00
CORD STRAIN RELIEF-UL MODELS
47
1
1086.00031.00
CORD STRAIN RELIEF CE MODELS
48
3
1073.00007.00
LEG-FLANGE FOOT
49
1
1104.00062.02
HOT WATER TANK 3X3KW/240VAC
49
1
1104.00074.02
HOT WATER TANK 3X5KW/240VAC
49
1
1104.00075.02
HOT WATER TANK 3X4KW/240VAC
49
1
1104.00080.02
HOT WATER TANK 2X3KW/240VAC
49
1
1104.00081.02
HOT WATER TANK 2X5KW/240VAC
50
2
B015280BN2
BREW BASKET-PLASTIC (STANDARD)
50
2
B001280B1
BREW BASKET-STAINLESS STEEL- (OPTIONAL)
