18/68
GB
4 INSTALLATION
1
4.4.2 Connecting to the pneumatic mains
Always use pneumatic hoses for compressed air with the maximum pressure
characteristics and cross section suitable for those of the compressor.
Do not try to repair a faulty hose.
Connect the compressor to the pneumatic mains using the fitting 1 pre-arranged on the compressor. Use
hosing with a greater or same diameter as the compressor outlet. Install two ball taps with capacity suitable
for the compressor between the compressor and tank and between the tank and line. Do not install non-
return valves between compressor and tank. The non-return valve is already installed inside the compressor.
