Fiamma ELEKTRA - Manufacture Constants; Setpoint and Parameters; Parameters; Temperatures

14
MANUFACTURE CONSTANTS
FUNCTION Value
MAX TEMPERATURE PRIMARY 80°C
TIME OF PUMP FUNCTIONING IN ANTI-LOCK 10 sec
INTERVENTION TIME ANTI-LOCK PUMP 24H
TEMPERATURE ANTIFREEZE ON (only circulator) 7°C
TEMPERATURE ANTIFREEZE ON (heat exchanger ignition) 4°C
TEMPERATURE ANTIFREEZE OFF 20°C
SETPOINT AND PARAMETERS
FUNCTION Default RANGE
HEATING SETPOINT 60°C 30 – 75 °C
FLOOR HEATING SETPOINT 30°C 10 – 40 °C
ROOM SETPOINT (with external probe present) 20°C 10 – 30 °C
PARAMETERS
FUNCTION N° Default RANGE
EXTERNAL PROBE START UP 1 0 0 – 1
BUILDING COEFFICIENT OF DISPERSION 2 35 5 – 35 °C
HEATING POST CIRCULATION
HEATING
EXCHANGER CIRCULATION STARTING
4
5
30
0
1 – 180 sec
0 – 240 sec
TEMPERATURES
FUNCTION N°
DELIVERY TEMPERATURE t: “Ch”
EXTERNAL TEMPERATURE t: “Ep”
OFFSET SETPOINT OF EXTERNAL PROBE t: “Se”
SELECTION JUMPERS enable
Jumper 0 / 1
JP7
JP8
High temperature / Low temperature plant
Combi / Only Heating
MIN. IGNITION TEMPERATURE CIRCULATOR 6 30 0 – 50 °C
SPEED PUMP PWM OPERATION 10 4 1=400 l/h - 2=800 l/h - 3=1000 l/h - 4=1200 l/h
