Parameters Table
FUNCTION N° def. RANGE
EXTERNAL PROBE ENABLING 1 0 0 – 1
BUILDING LEAKAGE COEFFICIENT 2 35 5 – 35 °C
HEATING POST CIRCULATION 4 30 1 – 180 sec
HEATING EXCHANGER CIRCULATION STARTING 5 0 0 – 240 sec
RANGE OF SETPOINT ADJUSTABLE BY MEANS OF REMOTE CONTROL
Interval of temperature setting with high temperature system
(JP7 = 0)
30 °C
÷ 75 °C - step 1°C
Pre-s
et value: 60 °C
Interval of temperature setting with low temperature system
(JP7 = 1)
15 °C ÷ 40 °C - step 1°C
Pre-s
et value: 30 °C
FUNCTIONING OF BOILER ELEKTRA WITH REMOTE CONTROL
The actuation of heating mode takes place after an heating request from remote control
(value of heating setpoint calculated by remote control higher than heating setpoint set by
the user on remote control divided by two) and in the winter mode status.
It also enabled the relay which controls the valve opening area managed by Enchrono/Kronos.
CONTROL PANEL IN USER MODE
The pressure of one key/two keys activates the backlighting of LCD display.
KEY FUNCTION
J5 Disabled in Opentherm mode
J6 Disabled in Opentherm mode
J7 Unlock error of safety thermostat
J4 Disabled in Opentherm mode
J2 Disabled in Opentherm mode
J3 Disabled in Opentherm mode
CONTROL PANEL IN INSTALLER MODE
The keys have the same functioning described on par. “Control panel in user mode”.
MIN. IGNITION TEMPER. CIRCULATOR 6 30
0 – 50 °C
