Fiamma ELEKTRA - Hydraulic Connections - Dimensional of Connection Arrangement; Bottom View (under the Boiler)

4
VSR
M
RC
R
Electrical
supply
220
165
40 95 80 120
 


  



 
Hydraulic connections – Dimensional of connection arrangement.
Hydraulic connections
M Heating delivery : ¾” M
R Heating return : ¾” M
VSR Heating safety valve (3 bar) : ½” F
R
C Manual Filling tap (restoring water pressure)
Bottom view (under the boiler)
