25DOORBELL MODE
Device operation
FIBARO Intercom allows to use rotating ring for entering PIN Codes set during the conguration process.
Correctly entered PIN code may result in authenticating the user and opening the gate.
Anyone who does not have a PIN code may use the button on the front to make a call.
To open the gate using the ring:
1) Move your hand close to the device - the button will light up in blue.
2) Rotate the ring to select the rst digit of your PIN code - numbers will light up one by one.
3) Push the ring to conrm selected digit.
4) Correct entering of the digit will be conrmed by turning o the backlight.
5) Enter next digits of your PIN code in the same way. If you entered incorrect digit, pull the ring to cancel the entire sequence and start
again from the 1st digit.
6) After selecting the last, 4th digit, make a single push to open the gate connected to the rst relay (R1).
Make a double push to open the gate connected to the second relay (R2).
7) The PIN code will be veried. In case of successful verication, all diodes will blink green ve times and the gate will be opened.
8) Entering incorrect PIN code will be indicated by two blinks in red.
The default time for which the gate stays opened is 3 seconds. Its length may be adjusted by the admin through the mobile app.
The gate may be opened by using the Bluetooth low energy proximity sensor. In order to do so, move your paired smartphone with
enabled Bluetooth connection close to the device.
To make a call:
1) Move your hand close to the device - the button will light up in blue.
2) Press the button.
3) LED diodes will start ashing - wait for a call.
4) If no one responds to your call, you will be able to leave your message in the voice mail.
Voice mail functionality:
Enabling the voice mail is indicated by the red button backlight, numbers ashing in red, and a beep.
Maximum length of the voice message is 30 seconds.
