FIBARO FGIC-001 - Use Cases; Gate Control Scenarios

26 USE CASES
Use cases
• Opening the gate with electromagnetic lock through the app
R2 R2R1 R112V GND N1 GND N2 TMP TMP
+
-
12/24V
• Opening the gate through the wall switch at your home or near the exit
R2 R2R1 R112V GND N1 GND N2 TMP TMP
+
-
12/24V
• Connecting external alarm device
R2 R2R1 R112V GND N1 GND N2 TMP TMP
ALARM
SYSTEM
