9
INSTALLATION - CHOOSING AND ROUTING WIRES
When routing wires take into consideration:
• The installation wires of the unit must be lead separately from the mains power wires to prevent the transmission interference and
overvoltage on the control lines.
• Wires inside the installation boxes should be as short as possible to prevent curling the wires and allow for easy assembling of the
in-wall part.
• Installation wires should be carried securely and not visible from the outside, preventing from the interference by unauthorized person.
• Recommended Ethernet cable for network connection is a twisted pair cable CAT-5e. The maximum cable length is 100 meters.
• Other inputs should be connected using the solid-core wires with cross-section from 0.14 to 0.34 mm
2
(26…22 AWG). Connectors are
also capable of connecting stranded wires.
• Close vicinity of mains (110V/230V) electrical wires may cause deterioration of the transmission through the Internet and potential
noise on the inputs.
