FIBARO FGKF-601 User Manual

6 7
OPERATING THE DEVICE
VISUAL INDICATIONS
#4: Operating the device
Waking up the device:
The KeyFob needs to be woken up to receive information about the
new conguration from the Z-Wave controller, like parameters and
associations. Use the 1
st
menu position (white) or click and simul-
taneously to wake up the device.
Menu enables you to perform Z-Wave network actions.
To use the menu:
1. Click
and simultaneously.
2. Click
or until LED indicates desired menu position with colour:
• White - wake up the device
• Green - learning mode (adding/removing)
• Cyan - check battery level
• Yellow - reset the device*
3. Click
to conrm selection, click to exit the menu.
4. LED pulses twice with same color as selected menu position to
conrm completing action.
Resetting the device to factory defaults:
Reset procedure enables restoring the device back to its factory set-
tings, which means all information about the Z-Wave controller and
user conguration is deleted. There are two ways of resetting the de-
vice:
Resetting the device using the menu:
1. Click
and simultaneously.
2. Click
or until LED glows yellow.
3. Click
.
Emergency resetting the device on start-up:
1. Remove the battery.
2. Hold
and , while inserting the battery.
Successful resetting is conrmed by smoothly brightening and
dimming of the yellow LED color.
NOTE
* Resetting the de-
vice from the menu
is not available in
Lock Mode.
NOTE
Resetting the device is
not the recommend-
ed way of removing
the device from the
Z-Wave network. Use
the reset procedure
only if the primary
controller is missing
or inoperable. Certain
device removal can be
achieved by the pro-
cedure of removing
described in "Adding/
removing the device"
on page 5.
i
i
#5: Visual indications
Visual indications:
The KeyFob is equipped with a LED diode, signalling pushing the but-
tons, sequences, menu position and status of the device.
What you see What it means What to do
Learning mode
Red blink Device not added
Click any button three
times to start adding
Fast white puls-
ing
Device in adding
mode
Wait for adding process
to end
Green blink Device added –
Lock Mode
Red blink Device locked Unlock using sequence
3 red pulses Wrong sequence Try unlocking again
Red to green
transition
Device unlocked
Press buttons to activate
scenes/associations
Green to red
transition
Device locked
using button hold
–
Battery
3 magenta pulses Low battery Replace the battery
Configuration
2 white pulses Device woken up –
Device status indications:
What you see What it means
Green blink
Receiving command conrmed by the con-
troller and associated devices
Yellow blink
every 1s
Sending commands in progress
Red blink
Receiving at least one command was not con-
rmed by the controller or associated devices
Indications for scenes and associations:
After pressing one of the buttons or using sequence, KeyFob indi-
cates status of action with the LED diode.
What you see What it means
Blue pulse Entering sequence
3 blue pulses Sequence valid
3 red pulses Sequence not valid
Indications for sequences:
