10 11
SEQUENCES
ACTIVATING SCENES
#8: Activating scenes
Activating scenes:
The KeyFob can activate scenes in the Z-Wave controller by sending
scene ID and attribute of a specic action using Central Scene Com-
mand Class.
By default scenes are activated after single clicking or pressing and
holding any of the buttons and sequences. Other actions can be acti-
vated with parameters 21-26.
Activating a double click introduces delay to a single click reaction
and activating a triple click introduces delay to a double click
reaction.
Button
Scene ID 1 2 3 4 5 6
Scene IDs of buttons:
Action Attribute
Button clicked once Key Pressed 1 time
Button clicked twice Key Pressed 2 times
Button clicked thrice Key Pressed 3 times
Button held Key Held Down
Button released Key Released
Sequence performed Key Pressed 1 time
Attributes of actions:
Sequence
number
1 2 3 4 5 6
Scene ID 7 8 9 10 11 12
Scene IDs of sequences:
#7: Sequences
Sequences:
User can create sequences of two to ve button to expand number
of possible actions. Every sequence sends corresponding Scene ID to
the Z-Wave controller with attribute "Key pressed 1 time" (see "Scene
activation" on page 11).
Sequences are saved in advanced parameters (no. 3-8).
Activating sequence introduces delay in single, double and triple
click actions for rst button in the sequence.
Rules of creating sequences:
• Maximum of six sequences can be created.
• Each sequence must be unique.
• Sequence can consist of two to ve button pushes.
• Sequence can contain multiple clicks of the same button.
Setting a new sequence using advanced parameter:
1. Calculate value of parameter using table and formula:
Value of parameter = Value of rst button +
+ 8 * Value of second button + 64 * Value of third button +
+ 512 * Value of fourth button + 4096 * Value of fth button
2. Change the value of corresponding parameter [2 bytes] (parame-
ters 3 to 8 for slots 1 to 6).
3. Click
and simultaneously to wake up the device.
4. Wait for the device to congure.
Button
Value 1 2 3 4 5 6
