FIBARO FGKF-601 User Manual

14 15
BATTERY
ADVANCED PARAMETERS
To add an association (using the Home Center controller):
1. Go to the device options by clicking the icon:
2. Select the „Advanced” tab.
3. Click the “Setting Association” button.
4. Specify to which group and what devices are to be associated.
5. Save the changes.
6. Click
and simultaneously to wake up the device.
Paired buttons associations
After pairing buttons, horizontal pairs of buttons ( and , and ,
and ) work as one button and send associations to left buttons
groups only.
Left buttons (
, , ) turn on associated devices and right buttons
(
, , ) turn them o.
In multilevel association groups (3, 7, 11) left buttons increase level
while holding and right buttons decrease it.
To pair buttons:
1. Change settings of parameters:
•
and – set parameter 6 to value 1
•
and – set parameter 7 to value 1
•
and – set parameter 8 to value 1
2. Save the changes.
3. Click
and simultaneously to wake up the device.
The KeyFob in the 2
nd
to 13
th
group enables you to control 5
devices (regular or multichannel) per an association group.
The “LifeLine” group is reserved solely for the controller and hence only
1 node can be assigned.
It is not recommended to associate more than 10 devices in general,
as the response time to control commands depends on the number of
associated devices. In extreme cases, system response can be delayed.
#11: Advanced parameters
1. Lock Mode - unlocking sequence
This parameter enables activating Lock Mode and set up unlock-
ing sequence. The device locks after time set in parameter 2 or after
pressing and holding selected button. See "Lock Mode" on page 9 for
more information.
Available settings: 0 - Lock Mode disabled
9-28086 - unlocking sequence
Default setting:
0
Parameter size: 2 [bytes]
2. Lock Mode - time to lock and locking button
This parameter enables setting time that must elapse from the last
press of the button to lock the device and locking button.
Setting locking button deactivates associations and scenes for press-
ing and holding the selected button.
This parameter is irrelevant if parameter 1 is set to 0 (Lock Mode
disable).
See "Lock Mode" on page 9 for more information.
Available settings: 0 - Lock Mode disabled
5-1791- calculated value
Default setting: 60 (60 s) Parameter size: 2 [bytes]
3. First scene sequence
This parameter enables setting up sequence that activates scene
with ID 7. See "Sequences" on page 10 for more information.
Available settings: 0 - 1st sequence disabled
9-28086 - value of sequence
Default setting:
0
Parameter size: 2 [bytes]
The KeyFob enables customizing its operation to user’s needs. The
settings are available in the interface as simple options that may be
chosen by selecting the appropriate box.
In order to congure the KeyFob (using the Home Center controller):
1. Go to the device options by clicking the icon:
2. Select the „Advanced” tab.
3. Modify values of chosen parameters.
4. Save the changes.
5. Click
and simultaneously to wake up the device.
NOTE
Entering invalid value
of parameter results in
response with Appli-
cation Rejected frame
and not setting the
value.
i

FIBARO FGKF-601 Specifications

General

Brand	FIBARO
Model	FGKF-601
Category	Remote Control
Language	English
