OPERATING THE DEVICE
#5: Operating the device
Controlling the Wall Plug using the B-button:
Wall Plug is equipped with a B-button, which allows to use the menu
and additionally perform the following actions:
1x click: turn controlled device ON/OFF, conrm selected menu op-
tion (if menu is active)
3x click: add/remove the device to/from a Z-Wave network
Holding: enter/navigate through menu
Visual indications:
The Wall Plug is equipped with a LED ring, signalling sensor’s oper-
ating modes and current active power consumption. In addition the
visual indicator may inform of the Z-Wave network range.
Visual indicator ring signalling modes:
1. By default, when the device is turned ON, the colour will vary de-
pending on the current active power consumption.
2. Once inserted to mains socket the device signals Z-Wave network
inclusion status with blink (green - added, red - not added).
3. Menu position is signalled with assigned illumination colour.
4. Ongoing software update is signalled with cyan blinking.
5. Range of the Z-Wave network with colour depending on type of
communication or the lack of it (only in range tester mode).
Menu allows to perform Z-Wave network actions. In order to use the
menu:
1. Press and hold the B-button.
2. Wait for the device to indicate desired position with a colour:
• GREEN - erase energy consumption memory
• VIOLET - Z-Wave network’s range test
• YELLOW - device reset
3. Release the B-button.
4. Click the B-button to conrm selection.
NOTE
Menu is preceded by
two white ashes of
the LED ring 6 seconds
after the B-button is
pressed.
i
CAUTION
To avoid risk of electri-
cal shock, do not ope-
rate the device with
wet or moist hands.
!
