AN6001-G16 Optical Line Terminal Equipment User Manual
2.12.1 Product Appearance
The AN6001-G16 is a small-sized cassette-shaped optical line access equipment
developed by FiberHome. It is designed with pluggable modularized power cards,
fan unit, core switch service cards and optical modules for easy installation,
deployment and maintenance. It provides GPON access, carrier-class reliability,
sound security mechanism and selective QinQ functions. The UNM2000 is used as
the network management system to enable centralized management, maintenance
and monitoring of the equipment.
The AN6001-G16 supports three power supply schemes: DC-AC, dual-DC, and
dual-AC. The figures below show the appearance of the equipment.
Figure 2-1 AC-DC Power Supply Scheme
Figure 2-2 Dual-DC Power Supply Scheme
Figure 2-3 Dual-AC Power Supply Scheme
4
Version: A
