AN6001-G16 Optical Line Terminal Equipment User Manual
5.6.45.6.4 Voice Service
This section introduces how to configure voice services for the AN6001-G16.
5.6.4.15.6.4.1 NGN Subscriber Data
This section introduces how to create, modify and delete NGN user data through the
Web GUI.
Planning Data
Item Description Example
SIP
Signaling Service
Name @ Interface
ID
Select Signaling Service Name and Interface ID
configured in NGN Interface.
voice@42
Signaling VLAN ID The voice service signaling VLAN
4084
SVLAN State
The QinQ enabling state. Configure this item according
to the network planning of the operator.
Disable
SVLAN ID
It is the SVLAN ID when QinQ is enabled. The SVLAN
ID should be within the uplink interface VLAN ID range.
It is invalid when QinQ is disabled.
-
Cos1
It is the outer VLAN priority when QinQ is enabled; it is
invalid when QinQ is disabled.
1
Cos2
It is the inner VLAN priority when QinQ is enabled; and it
is the single-tagged VLAN priority when QinQ is
disabled.
2
IP Config Mode
Select the way to configure the public network IP
address for the ONU. Static configuration or dynamic
obtaining of the IP address is supported.
Static
ONU Public IP
Configure this item according to the network planning of
the operator. When the DHCP or PPPoE function is
enabled, the IP address assigned to the ONU
dynamically will override the public network IP address
assigned to the ONU by the system.
IPv4:123.123.123.
182
ONU Public IP
Gateway
Configure this item according to the network planning of
the operator.
123.123.123.1
Endpoint Domain
Name/SIP User
Name Postfix
The domain name address of the gateway. Configure
this item according to the network planning of the
operator.
-
46
